Step by Step

If You Cannot Reach a Destination ...

Deleting a displayed entry:

Press the "OK" dialog key to confirm your selection

Ending callback display:

Select and confirm.

Press the key. The LED goes out.

Call Waiting (Camp-On)

Precondition: You have dialed an internal number and

hear a busy signal. It is important that you reach the

called party.

Wait (approx. 5 seconds) until "Camp-on" appears on the

display and the busy tone is followed by the ring tone.

The called party can then respond Æ page 14

Delete?

US: Exit?

UK: End?

Program/Service

Speaker

Camp-on

The called party can prevent automatic call wait-

ing Æ page 15.

If this feature is configured (contact the service

personnel), you will hear the ring tone and the

message "Camp-on" is immediately displayed.
