Figure1-6
Barrier box nameplat
e
Manufacture date
&RQV
HFX
WLYHQ
XP
E
H
U
-DQXD
U
\
3OD
FHRIPDQXI
DF
W
X
U
H
1
6
Q
X
P
Q
X
P
Q
X
P
F
W
X
Figure1-7
Example of a manufactur
e date (taken fr
om the
rst
nameplate in this paragraph)
Introduction
1.5Information on nameplates
LDS 6 & Optics housing CD 6 Compact Operating Instructions
Compact Operating Instructions, 12/2022, A5E03314905-AB
11
10
12
Table of Contents
Table of Contents
3
Introduction
5
Purpose of this Documentation
5
Intended Use
5
Range of Application
5
Set-Up of an LDS 6 System for Use in Hazardous Areas
6
Information on Nameplates
7
Notes on Warranty
13
Checking the Consignment
13
Transportation and Storage
13
Safe Use of the Device
15
Loss of Safety of Device with Type of Protection "Intrinsic Safety Ex I
16
Requirements for Special Applications
16
Safety Information
16
Qualified Personnel for Hazardous Area Applications
19
Laws and Directives
19
Conformity with European Directives
20
Conformity with UK Regulations
20
Installing/Mounting
21
Safety Notes
21
Site Requirements
23
Central Unit and Barrier Box
23
Direct Sunlight
24
LDS 6, Optics Housing CD 6
24
Safe Installation
24
LDS 6, Optics Housing CD 6 Installation
27
Installation of the Barrier Box
28
Electric Connections
31
Safety Notes
31
Unsuitable Cables, Cable Glands And/Or Plugs
31
Connecting the LDS 6, Optics Housing CD 6
33
Connection Diagrams
44
Commissioning
47
General Safety Notes
47
Optics Housing Side Purging
49
Process Side Purging
49
Service and Maintenance
51
Safety Notes
51
Service Instructions
52
Cleaning the Optical Parts of the Sensor
53
Decommissioning
57
Technical Data
59
Central Unit
59
CD 6 Optics Housing for Use in Hazardous Areas
60
Hybrid and Sensor Connection Cables
61
Barrier Box
61
Purging
62
Product Information on the Internet
63
Abbreviations
65
List of Abbreviations
65
Index
69
Other manuals for Siemens LDS 6
Operating Instructions
102 pages
Product Information
30 pages
Service Instruction
9 pages
