8.3 Hybrid and sensor connection cables
General 
Con󹪝guration hybrid ca‐
ble
Two optical 󹪝bers and two twisted copper wires in one cable for 24VDC.
Single-mode optical 󹪝ber con󹪝gured at both ends with E2000 angle connec‐
tors. Multimode optical 󹪝ber con󹪝gured at both ends with SMA connectors.
For installations in Ex zones non-intrinsically-safe cables have to be spatially
separated from intrinsically-safe lines
Cable sheath Oil-resistant polyurethane
Dimensions
- Diameter
- Length
<8mm (5/16"),
total length of the hybrid cable and sensor connection cable must not exceed
250 m (820 ft) in Ex zone 0 and Ex zone 1 installations and not exceed 700 m
(2300ft) in EEx zone 2 and non Ex installations.
For lengths >500 m (1 640 ft), an external power supply must be additionally
ordered.
Impact resistance 100N/cm
Maximum tensile
strength
200N (45 lbf)
Minimum bending radi‐
us
12cm (43/4")
Climatic conditions 
Ambient temperature -40...+80°C (-40...+176°F) during operation, transport and storage
-5 ... +50 °C (23...122°F) during installation
Rel. humidity <95% relative humidity, above dew point
8.4 Barrier box
Design, enclosure 
Degree of protection IP45 according to EN60529
Dimensions (without wall mounting kit) 400 x 240 x 155 mm (153/4x91/2x61/8")
Weight (fully equipped) Approx. 6.8 kg (15lbs.)
Permissible ambient temperature (operation) -20...+60°C (-4...140°F)
Technical data
8.4Barrier box
LDS 6 & Optics housing CD 6 Compact Operating Instructions
Compact Operating Instructions, 12/2022, A5E03314905-AB 61
