123/213

Building Technologies Basic documentation LMV37.4... CC1P7546en

HVAC Products 21 Operating the AZL2… unit 01.12.2009

21.5 Timeout for menu operation

The time for automatically leaving the parameter setting level can be adjusted between

10 and 120 minutes, using the following parameter:

No. Parameter

127 Timeout for menu operation

If, during that period of time, there is no operation via the AZL2..., the parameter setting

level is quit and the password level reset to

Info / Service.

Caution!

In addition, this timeout or interruption of communication between the

LMV37.4... and the AZL2... during the time the curves are set leads to lockout!

Error-

code

Diagnostic

code

Meaning for the LMV37… system

167 8 Manual locking via AZL2...

Timeout / communication interruption
