26.11.3 Setting curvepoints P0 and P9 for «G mod pneu», «Gp1 mod pneu»

and «Gp2 mod pneu»

Note

Refer to subsection Setting curvepoints P0 and P9 for modulating mode («G mod», «Gp1

mod», «Gp2 mod» and «Lo mod»)!

Here, only the air must be adjusted with A .
