Building Technologies Basic documentation LMV37.4... CC1P7546en
HVAC Products 6 Basic unit 01.12.2009
Functions with fixed repetition counters
These counters cannot be set.
Settings
Meaning
Unit Basic setting
Number of repetitions in the event of error:
- Speed standardization VSD
- Speed error
- Referencing error actuator
- Positioning error actuator
Recharging time:
- End of Shutdown phase
--- 3
Number of repetitions in the event of error:
- Relay
- Relay control
Recharging time:
- End of Operation phase
--- 2
Number of repetitions in the event of internal errors
Recharging time:
- After 24 hours of operation
--- 5
Error
code
Diagnostic
code
Meaning
82 # Error during speed standardization of the VSD
83 # Speed error VSD
85 # Referencing error of an actuator
86 # Error fuel actuator
87 # Error air actuator
95…98 # Error relay supervision
99…100 # Internal error relay control
