Siemens LMV51.140C1 Technical Instructions

LMV Series Technical Instructions
Document No. LV5-10
00
SCC Inc. Page 13 Section 1
Flame Scanner Accessories (continued)
QRA75… Accessories - Optional
Mounting accessories are available for the
QRA75… flame scanner. For more information, refer
to Document No. N7712.
AGG16.U
Right angle adapter for mounting
a QRA75 flame
scanner. Comes with a 1” NPSM female thread
connection
THERMAL-1X75
Thermal barrier for use with t
he QRA75 flame
scanner along with accessory AGG16.U. Adapts a 1”
NPSM thread to a female 3/4” NPT connection
AGG02
Heat insulating glass with spring washer
and O-ring,
for applications where the temperature at the
scanner will exceed 176 °F, to be mounted inside
thermal barrier THERMAL-1X75
AGG03
Magnifying lens with spring washer
and O-ring for
increased sensitivity, to be mounted inside thermal
barrier THERMAL-1X75
