4
08/2005 Creating a ShopTurn Program
4
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 4-141
The machine manufacturer only sets one speed limit for the machine,
i.e. none that are dependent on the workpiece.
Please also refer to the machine manufacturer's instructions.
Press the "Program" softkey.
Select the directory in which you want to create a new program.
New
ShopTurn
program
Press the "New" and "ShopTurn program" softkeys.
Enter a program name.
Program names may be a maximum of 24 characters in length.
You can use any letters, digits or the underscore symbol (_).
ShopTurn automatically replaces lowercase letters with uppercase
letters.
-or-
Press the "OK" softkey or the "Input" key.
The parameter screen form “Program Header” is displayed.
Set program header parameters
Work
offset
Select a zero-point offset or input a zero-point offset directly into
the input field or call up the zero-point offset list using the "Work
offset" softkey if you want to select a zero-point offset there.
Input the other parameters.
