PID Control
P416-01 External Setpoint E
Setpoint 0
P418-01 Remote Setpoint Ratio V
Enter % of Master Output 100.000
P250-01 mA Input Range E
Select 1- 0 to 20, 2-4 to 20 2
P255-01 mA Input Function E
Select 0, 1-PID SP, 2-PID PV 0
Assign either:
1. PID setpoint, or
2. process variable as the
function of the mA input
Select the appropriate range for the mA
input signal
Increase or decrease to scale input
setpoint, if desired.
Current setpoint value in engineering units,
obtained from the mA input
