Batching
Programming
The pre-warn function is optional.
The setpoint associated with the pre-warn relay is entered in P564, batch setpoint.
The setpoint associated with the batch relay is entered in P567, batch pre-warn setpoint.
Batch Operation
Access P560 Batch Mode Control Select 1, enable batch operation
Access P564 Batch Setpoint Enter the desired batch total
Access P566 Batch Pre-warn Set to ON (1) or leave it OFF (0)
If batch pre-warn is selected, access P567
Batch Pre-Warn Setpoint
Enter the Pre-warn total
Access P568 Batch Pre-act Set to OFF (0) or AUTO (1) or manual (2)
Relays
Access P100, Relay Function
Select relay (1 – 5)
Select function 5, Pre-Warn
Access P100 Relay Function
Select relay (1-5, other than the pre-warn
relay)
Select function 6, Setpoint
