7ML19985CN01 Milltronics SF 500 - INSTRUCTION MANUAL Page 83
mmmmm
Communications
Error Codes
The error codes returned in the format area are 8-bit integers found in the lowest 8 bits of
the format word. This allows for 256 potential error codes.
Currently the SF 500 has two error codes available:
Date and Time (R41,000 – 41,006)
The date and time can be read or written in registers 41,000 to 41,006 as defined in the
table above.
Example: If you are located in Toronto, Canada and would like to set the date and time to
February 14, 1999, 1:30 p.m. and 42 seconds, you would write the following:
Values Description
0No error
1 Data not available as percent (available as units)
2-255 Reserved
Bits Values
R41,000 1999
R41,001 2
R41,002 14
R41,003 13
R41,004 30
R41,005 42
R41,006 -5
Note: The time zone register is used only as a reference and does not affect the
operation of the SF 500.
