LIS 1
LIS 1 allows communication to external printers, for example the 800
series ticket printer, or to data collection systems which accept
asynchronous, unidirectional data transmission.
Data Format
Baud rate 9600
Start bit 1
Stop bit 1
Data bits 8
Parity OFF
The transmitted data will have the same format as the data sent to the
internal printer.
LIS 3
LIS 3 allows communication to Complement 2, and HIS and LIS
systems.
Data Format
Baud rate 9600
Start bit 1
Stop bit 1
Data bits 8
Parity OFF
The transmitted data will have the format and protocol defined in the
248 Interface Manual.
Connecting to a 270
Equipment: 270 interface cable (Cat. 673365).
Select CMSI on the 248.
Following the instructions in the 270 Operator’s Manual, connect the
248, as a 200 series instrument, to the 270.
Connecting to Complement 2
Equipment: Complement 2 interface cable (Cat. 673379).
Select LIS 3 on the 248.
Following the instructions in the Complement 2 Manual, connect the
248.
Page D-2 248 Operator’s Manual
