The Rear Panel
Figure 1-3. The Rear Panel
Memory Card Slot
Slope Gas
Connector
Tubing
Cal Gas
Connector
Tubing
Power Connector,
Voltage Selector
and Fuses
These symbols appear on the rear of the instrument.
Symbol Description
Port 1 Data Port 1, 9-way D-line
Port 2 Data Port 2, 9-way D-line
Status Status Indicators
Indicators
Indicates that the input electricity is alternating current
Shows the manufacturer of the serial plate (Donprint)
Indicates an in vitro diagnostic device
Manufacturer
Cautions you about the risk of exposure to potential electrical hazards
Advises you to consult the instructions for use to obtain safety related
information.
Page 1-2 248 Operator’s Manual
