Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
114 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
8000bxxx
8000cxxx
Software did not
allocate enough
memory for user’s
current setup.
Try disabling items
connected or disabling Auto
Dual View.
If error persists, replace
Main Processor Board
Subassembly.
800c9009 atten OOR = A cal factor = B Speaker too quiet Replace speaker
800c9022 cal factor=A max_sample_value=B Speaker broken Replace speaker
800cd007 Loopback Active = A Expect Active =B Hardware malfuction
in “nurse call” circuit.
Check “Nurse Call” circuit.
800d3xxx
800d4xxx
800d5xxx
800d6xxx
Cardiac Output-related Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
800d7xxx
800d8xxx
Temperature - related (MultiMed Pod) Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
800d9xxx
800daxxx
Pod communications
problem.
Pod cable, Pod, or
CPU board failed
Try disconnecting/
reconnecting cable.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
