Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
122 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
8020fxxx
80210xxx
Software did not
allocate enough
memory for user’s
current setup.
Try disabling items
connected or disabling Auto
Dual View.
If error persists, try
upgrading SW to currently
released version.
If error persists, replace
Main Processor Board
Subassembly.
80231002 LCOM_BAD_PRL_SUPPLIED_ERROR SW or comm error
between CPS or IDS
and Monitor
Check cable connection. If
no second error, replace
CPS or IDS.
80231005 LCOM_BAD_SWITCH_COUNT_ERRO
R
Comm error If this message is
accompanied by another
error, check Docking station
connections. Otherwise this
indicates a SW error and
should be reported to
Customer service via
DataCard.
8023100a LCOM_CHECKSUM_DIAG_ERROR Comm error If this message is
accompanied by another
error, then check Docking
station connections.
Otherwise this indicates a
SW error and should be
reported to Customer
service via DataCard.
80231025 LCOM_PRL_ENTRY_DIAG_ERROR CPS or IDS harware
failure
Reboot monitor and CPS or
IDS. If problem persists,
replace CPS or IDS.
80231026 LCOM_PRL_ID_DIAG_ERROR CPS or IDS hardware
failure.
Reboot monitor and CPS or
IDS. If problem persists,
replace CPS or IDS.
8023102b LCOM_RAM_DIAG_ERROR Net comm failure If this message is
accompanied by another
error, check Docking station
connections. Otherwise this
indicates a SW error and
should be reported to
Customer service via
DataCard.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
