Siemens SC 7000 Service Manual

SC 7000 and SC 9000XL Patient Monitors Service Manual
ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 129
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
NOT A CONTROLLED DOCUMENT
80311xxx
80312xxx
Network Communications - related Try disconnecting/
reconnecting cable(s)
between Monitor and
network wallbox.
Verify proper SW version(s)
installed in all related
devices, in accordance with
SW compatibility chart for
Monitor SW.
If problem persists, try
swapping CPS/IDS with
known-good device.
If problem persists, replace
Main Processor Board
Subassembly.
80323003 Watchdog fired reset Upgrade SW to ≥VC1.x.
80325001 Speaker Out of Range value: A Failed speaker, CPU
board or front panel
board
If sound is heard replace
Front Panel Board.
Otherwise, replace Main
Processor Board
Subassembly
80359xxx
8035axxx
Network Communications - related Try disconnecting/
reconnecting cable(s)
between Monitor and
network wallbox.
Verify proper SW version(s)
installed in all related
devices, in accordance with
SW compatibility chart for
Monitor SW.
If problem persists, try
swapping CPS/IDS with
known-good device.
If problem persists, replace
Main Processor Board
Subassembly.
8035bxxx
8035cxxx
Serial Interface to Remote Keypad -
related
Try disconnecting/
reconnecting keypad.
If problem persists, swap
cable with known-good
keypad.
If problem persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
