Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
128 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apc.CD_ROM.fm/04-99/kaupp
802dfxxx
802e0xxx
SPO2 - related Try disconnecting/
reconnecting cable.
If problem persists, try
replacing sensor.
If problem persists, swap
cable with known-good
cable.
If problem persists try
swapping pod.
If problem persists, replace
Main Processor Board
Subassembly.
802e701c Powering up the System... Power was turned on. Ignore
802e701d Indicates that new
software was
installed
No action nessessary
802ef011 trends completely cleared, new sofware
loaded
Software warning Ignore
802f1xxx
802f2xxx
Network Communications - related Try disconnecting/
reconnecting cable(s)
between Monitor and
network wallbox.
Verify proper SW version(s)
installed in all related
devices, in accordance with
SW compatibility chart for
Monitor SW.
If problem persists, try
swapping CPS/IDS with
known-good device.
If problem persists, replace
Main Processor Board
Subassembly.
8030500d b A a=B w=C d=D 0 e=E 0 s=F rx=G
ok=H flags=I df=J,K
SW error Replace Main Processor
Board Subassembly.
80309xxx
8030axxx
Try upgrading SW to
currently released version.
If error persists, replace
Main Processor Board
Subassembly.
Table C-1Diagnostic Log Codes (Continued)
Code
xxx = any
alphanumeric
characters
Description Cause Action
