Siemens SCALANCE X308-2 User Manual

Description of the device
4.5 Components of the product
SCALANCE X-300
100 Operating Instructions, 05/2016, A5E01113043-20
Table 4- 1 Overview of the components shipped with the
X-300M
product group
Device:
SCALANCE
Variant
Plug-in terminal block
Device
BAK
Product CD
Signaling
contact
Power supply
X308-2M
(-)
2-pin
4-pin (24 V)
●
●
●
X308-2M TS
(-)
2-pin
4-pin (12 V)
●
●
●
4.5.3
Components of the XR-300M product
Note
When
shipped, the slots for the media modules have dummy covers fitted.
Note
Labels to identify the installed MM900 media modules are supplied with the modular devices
(M).
The following parts ship with a SCALANCE XR-300M:
● Device with C-PLUG exchangeable medium.
● 2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
installation.
● A two-pin terminal block for the signaling contact.
● Connecting cable for the diagnostics port.
● Adhesive feet for desktop operation.
● Product CD with documentation and software.
For devices with a 100 to 240 VAC power supply also:
● A two-pin connector for the power supply.
For devices with a 24 VDC power supply, also:
● A four-pin terminal block for the power supply.
