Description of the device
4.4 C-PLUG (configuration plug)
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
95
IE Switches X-300 connector technology
SC duplex female connectors are used.
Connector technology of the IE Switch X-300EEC
FC duplex female connectors with the following characteristics are used:
Maximum range: up to 3 km
Wavelength: 1310 nm
Transmission mode: Multimode
Standard: 100Base-FX
4.3.3
Signaling contact
The signaling contact (relay contact) is a floating switch with which error/fault states can be
signaled by breaking the contact.
Error indication
The signaling by the signaling contact is synchronized with the fault LED, in other words,
all errors displayed by this LED (freely configurable) are also signaled on the signaling
contact.
If an internal fault occurs, the fault LED lights up and the signaling contact opens.
The connection or disconnection of a communication node on an unmonitored port does
not lead to an error message.
The signaling contact remains activated until the error/fault is eliminated or until the
current status is entered in the fault mask as the new desired status.
4.4
C-PLUG (configuration plug)
NOTICE
DO NOT REMOVE C-PLUG WHILE POWER IS ON
The C-PLUG may only be removed or inserted when the power supply to the device is
turned off.
In a device with a varnished printed circuit board, you may only use a C-PLUG with a
varnished board.
