SCALANC
E X
-
300
Operating Inst
ructions
,
05/2016
,
A5E01113043
-
20
175
8-1
Block ar
chitecture of
the XR32
4
-
12M
8-2
Block ar
chitecture of
the XR32
4
-
4M
8.4.5
Other prop
erties
Table
8-
45
Switching propert
ies
Max. number
of learnable
addr
esses
8000
Aging tim
e
30 sec
Switching t
echnique
Store and for
ward
Latency
5 μs
174
176
