8.6 XR-300M EEC technical specifications
SCALANCE X-300
184 Operating Instructions, 05/2016, A5E01113043-20
Construction, installation and environmental conditions
Table 8- 67 Construction
Device version
(power supply)
XR324-4M
EEC
2 x 24 to 48 VDC 483 × 44 × 305 mm 6800 g IP20
1 x 100 to 240 VAC / 60 to
483 × 44 × 305 mm 6600 g IP20
2 x 100 to 240 VAC / 60 to
483 × 44 × 305 mm 7000 g IP20
Table 8- 68 Installation options
1)
Note: If mechanical load is high, the device should be secured at four points. You will find more
detailed information in the section "Mechanical load in operation".
Table 8- 69 Permitted ambient conditions
Storage/transport temperature
Max. relative humidity in operation at 25 °C
Max. ambient temperature at operating altitude 2000 m or above:
-5 °C of the max. operating temperature
1)
3000 m or above:
-10 °C of the max. operating temperature
1)
1)
See table: "Operating temperature depending on the media modules used"
Table 8- 70 Operating temperature depending on the media modules used
Without media module
