Description of the device
4.5 Components of the product
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
101
4.5.4
X-300EEC product components
Apart from the device itself, the following components are also supplied with the switch:
Table 4- 2 Overview of the components shipped with the X-300EEC product group
Device:
SCALANCE
(variants)
Components of the product
C-PLUG
Plug-in terminal block
Product CD
Signaling contact
with contact pins
Power
DC
24 to 48 V
AC
100 to 240 V
/ DC
60 to 250 V
X302-7EEC
1 x power supply unit 24 VDC,
1 x 2-pin
1 x 4-pin
-
2 x power supply unit 24 VDC
2 x 2-pin
2 x 4-pin
-
1 x power supply unit 100 to 240 VAC / 60
to 250 VDC
1 x 3-pin - 1 x 3-pin
2 x power supply unit 100 to 240 VAC / 60
to 250 VDC
2 x 3-pin - 2 x 3-pin
X307-2EEC
1 x power supply unit 24 VDC
1 x 2-pin
1 x 4-pin
-
2 x power supply unit 24 VDC
2 x 2-pin
2 x 4-pin
-
1 x power supply unit 100 to 240 VAC / 60
to 250 VDC
1 x 3-pin - 1 x 3-pin
2 x power supply unit 100 to 240 VAC / 60
to 250 VDC
2 x 3-pin - 2 x 3-pin
4.5.5
Components of the XR-300M EEC product
Note
When shipped, all devices have a C-PLUG exchangeable medium.
When shipped, the slots for the media modules have a dummy cover fitted.
Labels to identify the installed MM900 media modules are supplied with the modular
devices.
The consignment of a SCALANCE XR-300M EEC consist of the device itself and the
following parts:
2 mounting brackets and 8 screws (M3x5 recessed head, drive: Torx) for 19" rack
installation
Connecting cable for the diagnostics port
Operating Instructions (compact) SCALANCE XR-300 M EEC.
