Technical specifications
8.5 Technical specifications for X-300EEC
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
181
Table 8- 59 Overvoltage category
In the application range of EN 60255-27
Table 8- 60 Permitted cable lengths (copper cable - Fast Ethernet)
Accessory (plug, outlet,
TP cord)
IE TP torsion cable with IE FC Outlet RJ-45
0 to 45 m
with IE FC RJ-45 Plug 180
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC Outlet RJ-45
0 to 75 m
with IE FC RJ-45 Plug 180
IE FC TP standard cable with IE FC Outlet RJ-45
0 to 90 m
with IE FC RJ-45 Plug 180
Table 8- 61 Permitted cable lengths (copper cable - gigabit Ethernet)
Accessory (plug, outlet,
TP cord)
IE FC Standard Cable, 4 × 2, 24
AWG
IE FC Flexible Cable, 4 × 2, 24
with IE FC RJ-45 Plug 180,
4 × 2
0 to 90 m
IE FC Standard Cable, 4 × 2, 22
with IE FC Outlet RJ-45
0 to 60 m
IE FC Flexible Cable, 4 × 2, 22
with IE FC Outlet RJ-45
0 to 90 m
Table 8- 62 Permitted cable lengths (fiber-optic cable - Fast Ethernet)
62.5/125 μm
50/125 μm,
0 to 5 km ≤1 dB/km at 1310 nm; 1200 MHz×km; maximum insertion loss
0.5 dB; 9 dB max. permitted FO cable attenuation at 3 dB link
power margin
