Technical specifications
8.6 XR-300M EEC technical specifications
SCALANCE X-300
188 Operating Instructions, 05/2016, A5E01113043-20
Table 8- 78 Permitted cable lengths (copper cable - Fast Ethernet)
Accessory (plug, outlet,
TP cord)
IE TP torsion cable with IE FC Outlet RJ-45
0 to 45 m
with IE FC RJ-45 Plug 180 0 to 55 m
IE FC TP Marine Cable
IE FC TP Trailing Cable
IE FC TP Flexible Cable
with IE FC Outlet RJ-45
0 to 75 m
with IE FC RJ-45 Plug 180
IE FC TP standard cable with IE FC Outlet RJ-45
0 to 90 m
with IE FC RJ-45 Plug 180
Table 8- 79 Permitted cable lengths (copper cable - gigabit Ethernet)
Accessory (plug, outlet,
TP cord)
IE FC Standard Cable, 4 × 2, 24
AWG
IE FC Flexible Cable, 4 × 2, 24
with IE FC RJ-45 Plug 180,
4 × 2
0 to 90 m
IE FC Standard Cable, 4 × 2, 22
with IE FC Outlet RJ-45
0 to 60 m
IE FC Flexible Cable, 4 × 2, 22
with IE FC Outlet RJ-45
0 to 90 m
Note
Permitted cable lengths (fiber-optic cable - Fast Ethernet or gigabit)
The values correspond to those of the
permitted MM900 media modules and SFP
To Next Page
