Technical specifications
8.6 XR-300M EEC technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
187
Table 8- 74 Electrical data: Overcurrent protection
Device version
(power supply)
Overcurrent protection of the power supply
Non-replaceable fuse
1 x 24 to 48 VDC
1 x T2H / 250 V
2 x 24 to 48 VDC 2 x T2H / 250 V
1 x 100 to 240 VAC / 60 to 250 VDC 1 x T2H / 250 V (AC)
1 x T2H / 300 V (DC)
2 x 100 to 240 VAC / 60 to 250 VDC 2 x T2H / 250 V (AC)
2 x T2H / 300 V (DC)
Table 8- 75 Electrical data: Signaling contact
Device version
(power supply)
Voltage via signaling contact
Switching capacity
(resistive load)
24 to 48 VDC
24 VDC
max. 0.1 A
100 to 240 VAC / 60 to 250
VDC
240 VAC
max. 5 A
60 VDC
max. 0.4 A
125 VDC
max. 0.22 A
250 VDC
max. 0.11 A
Table 8- 76 Plug-in terminal block for connectors of the power supply and signaling contact
Device version
(power supply)
Power supply
Signaling contact
1 x 24 to 48 VDC
1 x 4-pin
1 x 2-pin
2 x 24 to 48 VDC
2 x 4-pin
2 x 2-pin
1 x 100 to 240 VAC / 60 to
250 VDC
1 x 3-pin 1 x 3-pin
2 x 100 to 240 VAC / 60 to
250 VDC
2 x 3-pin 2 x 3-pin
Table 8- 77 Overvoltage category
General
Overvoltage category II
In the application range of EN 60255-27
Overvoltage category III
