Technical specifications
8.5 Technical specifications for X-300EEC
SCALANCE X-300
178 Operating Instructions, 05/2016, A5E01113043-20
Table 8- 50 Permitted ambient conditions
Storage/transport tem-
perature
Max. relative hu-
midity in operation
at 25 °C
Max. ambient temperature
at operating altitude
-40 °C to +70 °C -40 °C to +70 °C
1)
<= 95% (no con-
Max. 65 ℃ as of 2000 m
1)
The IE Switch was type tested for 16 h at +85 °C.
Table 8- 51 Mechanical stability
Strain withstood / category (stand-
ard)
Vibration
(IEC 60068-2-6)
Frequency range 10 Hz to 150 Hz:
• Transit frequency: 58 Hz to 60 Hz
• Peak value of the displacement [mm] below the transit
frequency: 0.075
• Peak value of the acceleration [g] above the transit fre-
quency: 1
• Number of cycles per axis: 20
Frequency range 5 Hz to 150 Hz:
• Transit frequency: 8.4 Hz
• Peak value of the displacement [mm] below the transit
frequency: 3.5
• Peak value of the acceleration [g] above the transit fre-
quency: 1
• Number of cycles per axis: 10
• Octaves / min: 1
Frequency range 2 Hz to 100 Hz:
• Frequency range: 2 Hz to 100 Hz
• Transit frequency: 13.2 Hz
• Peak value of the displacement [mm] below the transit
frequency:1
• Peak value of the acceleration [g] above the transit fre-
quency: 0.7
• Number of cycles per
Vibration
(IEEE1613 Class V.S.2)
• Velocity: <10 mm/s
• Frequency: 1 to 150 Hz
Shock
(IEC 60068-2-27)
• Acceleration: 15 g
• Duration of the pulse: 11 ms
• Number of shocks per direction: 3
