Siemens SCALANCE X308-2 User Manual

Technical specifications
8.9 MM900 technical specifications
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
211
Media module
Cable
Permitted cable length
IE FC TP marine/trailing/ flexible cable
with IE FC RJ-45 Plug 180
0 to 85 m
IE FC TP standard cable with
IE FC Outlet RJ-45 + 10 m TP cord
0 to 90 m
+ 10 m TP cord
IE FC TP standard cable
with IE FC RJ-45 plug 180
0 to 100 m
MM992-2VD (with VD)
2)
IE FC TP standard cable GP 4X2 (24
AWG) with IE FC RJ-45 plug 4x2
0 to 500 m at 100 Mbps
IE FC TP standard cable GP 2x2
with IE FC RJ-45 plug 2x2
0 to 300 m at 100 Mbps.
IE FC TP standard cable GP 2x2
with IE FC RJ-45 plug 2x2
300 to 500 m at 10 Mbps
PROFIBUS FC standard cable GP
with IE FC RJ-45 plug 4x2
100 to 1000 m at 10 Mbps
PROFIBUS FC standard cable GP
with IE FC RJ-45 plug 4x2
0 to 100 m at 100 Mbps.
1)
The VD mode (Variable Distance) is turned off.
2)
The VD mode (Variable Distance) is turned on.
Table 8- 128 Permitted cable lengths (copper cable - gigabit Ethernet)
Media module
Cable
Permitted cable length
MM992-2CUC
MM992-2CUC (C)
MM992-2CU
MM992-2M12 (C)
MM992-2VD (without
VD)
1) 2)
IE FC standard cable, 4×2, 24 AWG
IE FC flexible cable, 4×2, 24 AWG
with IE FC RJ-45 Plug 180,
4x2
0 to 90 m
IE FC standard cable, 4×2, 22 AWG
with IE FC Outlet RJ-45
+ 10 m TP cord
0 to 60 m
+ 10 m TP cord
IE FC flexible cable, 4×2, 22 AWG with
IE FC Outlet RJ-45
+ 10 m TP cord
0 to 90 m
+ 10 m TP cord
1)
The VD mode (Variable Distance) is turned off.
2)
If the VD mode is turned on, the speed is reduced to 100 Mbps. For permitted cable lengths, see
table Fast Ethernet.
