Siemens SIMATIC Box PC 820 User Manual

2-3
Box PC 820 / PC FI45 V2, Manual
A5E00051531-03
2.1 Components and Interfaces
Component/
Interface
Description Parameters
CPU - base Slot 1 for micro processor card, up to
500 MHz
S Can be upgraded via SLOT 1
S Multimedia support
S ECC
Memory DIMM module
up to max. 256 Mbyte/DIMM
S Data width 64 Bit + ECC
S Module with ECC possible
S 3.3 V
S SDRAM according to PC100
specifications
S up to 128 Mbit chip size on the module
S 100 MHz bus clock
S 3 DIMMs can be inserted
S easy to replace
S variable from 64-256 Mbyte/DIMM
Chipset Single chip set 440LX
S SDRAM
S ECC support
Hard Disk ATA-33 mode
S Ultra DMA capable
DP12 Communication port SIMATIC S7
S optically isolated DP12 *
(CP 5611 compatible)
S 12Mbps
TTY Communication with SIMATIC S5-CPUs
S Range up to 1000 m
USB Universal Serial Bus
S high current (500mA)-USB-Port
Ethernet 10BaseT(100Base-TX
S 10/100 Mbps, Galvanic isolation *)
Floppy Standard port for 34-pin ribbon cable
S 1.44 Mbyte
Keyboard Port for PS2 keyboard
S Standard
S Trackball supported
(on PS/2 jack on side housing)
Mouse PS2 mouse port
S Standard
Serial COM1/25-pin
COM2/9-pin
S TTY and V24
S Standard
Parallel Standard-, bidirectional, EPP and
ECP mode
S 25-pin sub-D
BIOS Update via software
S 512K in 4 pages
CD-ROM
S 24 times speed
* Galvanic isolation within the safety extra-low voltage circuit (SELV)
