Siemens SIMATIC ET 200SP IM 155-6 DP HF User Manual

Product overview
2.1 Properties
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
13
Properties
The module has the following technical properties:
● Connects the ET 200SP distributed I/O system with PROFIBUS DP
● Power supply 1 L+ 24 V DC (SELV/PELV)
● Bus connection via RS485 interface
The module supports the following functions (Page 14):
Maximum configuration
● 244 bytes I/O data
● 32 I/O modules and 16 ET 200AL modules
Accessories
You order the following accessories separately:
● Labeling strips
● Reference identification label
You can find additional information on the accessories in the ET 200SP distributed I/O
system (http://support.automation.siemens.com/WW/view/en/58649293) system manual.
Server module
The server module is included in the product package of the interface module and available
separately as an accessory.
The server module has the following properties:
● Terminates the backplane bus of the ET 200SP distributed I/O system
● Features a support for 3 spare fuses (5 × 20 mm)
● Provides station functions, e.g., status bytes
● Identification data I&M 0 to 3
Note
You need to configure the server module in the configuration software
.
To do so, place the server module with the required length of status bytes at the last slot of
the configuration. When there are 32 I/O modules, the server module is inserted at slot 33.

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
