Interrupts, error messages, diagnostics and system alarms
5.3 Alarms
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
41
Station statuses 1 to 3 provide an overview of the status of a DP slave.
Structure of station status 1 (byte 0)
Table 5- 7 Structure of station status 1 (byte 0)
0 1: The DP slave is not responding to the DP
master.
• Is the correct PROFIBUS address set on
the DP slave?
• Is the bus connector plugged in?
• Is the DP slave connected to the voltage
supply?
• Is the RS485 repeater properly config-
ured?
1 1: The DP slave is not yet ready to ex-
change data.
• Wait; the DP slave is currently starting
up.
2 1: The configuration data transferred from
the DP master to the DP slave does not
match the DP slave configuration.
• Has the correct station type or the cor-
rect DP slave configuration been en-
tered in the configuration software?
3 1: External diagnostics is available. (Group
diagnostics display)
• Evaluate the ID-specific diagnostics, the
module status, and/or the channel diag-
nostics. As soon as all errors have been
eliminated, bit 3 is reset. The bit is set
again when there is a new diagnostics
alarm in the bytes of the aforementioned
diagnostics.
4 1: The required function is not supported by
the DP slave (for example, changing the
PROFIBUS address by means of software).
• Check the configuration.
5 1: The DP master cannot interpret the re-
• Check the bus configuration.
6 1: The DP slave type does not match the
software configuration.
• Has the correct station type been en-
tered in the configuration software?
7 1: Parameters have been assigned to the
DP slave by a different DP master (not the
one that currently has access to the DP
slave).
• The bit is always 1, for example, if you
access the DP slave with the program-
ming device or another DP master.
• The PROFIBUS address of the DP mas-
ter that assigned parameters to the DP
slave is located in the "Master
PROFIBUS address" diagnostics byte.
