Siemens SIMATIC ET 200SP IM 155-6 DP HF User Manual

Parameters/address space
4.2 Description of parameters
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
22 Manual, 10/2018, A5E03916550-AD
4.2
Description of parameters
4.2.1
Configuration control
You can use this parameter to enable the configuration control function in the ET 200SP
distributed I/O system.
Note
Configuration control
The "Configuration control" function can only be used if you set the parameter "Startup if
p
reset configuration does not match actual configuration" to yes at the same time.
Note
Configuring the enable
If you configure the enable, the ET
200SP distributed I/O system requires control data record
196 from the user program so that the ET
200SP distributed I/O system can operate the I/O
modules.
Reference
You can find additional information in the ET 200SP distributed I/O system
(http://support.automation.siemens.com/WW/view/en/58649293) system manual and in the
STEP 7 online help.

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
