Parameters/address space
4.3 Substitute value behavior
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
24 Manual, 10/2018, A5E03916550-AD
4.3
Substitute value behavior
The substitute value behavior is implemented by the DP master per slot in the ET 200SP
distributed I/O system.
The respective output reacts according to its configured substitute value behavior:
● Current-free/voltage-free
● Keep last value
● Output substitute value
The substitute value behavior is triggered in the following cases:
● STOP DP master
● DP master failure (connection interruption)
● Firmware update
● Station stop, for example, due to:
– No server module
– At least one I/O module installed on an incorrect BaseUnit
● Deactivate DP slave
Note
Reducing a configuration
If you reduce the configuration of the ET
200SP distributed I/O system and download the
new configuration to the CPU, the modules no longer configured but still
present retain
their original substitute value behavior. This applies until the supply voltage on the
BaseUnit BU...D or on the interface module is switched off.
The "current-free/voltage-free" behavior takes effect in the following cases:
● Firmware update
● Configuration control: receipt of a new control data record
● Incorrectly configured module
● Module with incorrect parameter assignment

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
