Siemens SIMATIC ET 200SP IM 155-6 DP HF User Manual

Product overview
2.2 Functions
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
14 Manual, 10/2018, A5E03916550-AD
PROFIBUS FastConnect bus connector
The PROFIBUS FastConnect bus connector is included in the product package of the
interface module and also available separately as an accessory.
You can find additional information on the PROFIBUS FastConnect bus connector in the
corresponding product information on the Internet
(http://support.automation.siemens.com/WW/view/en/58648998).
Configuration with more than 244 bytes of parameter data
With a configuration as of STEP 7 V5.5 SP 3 with HSP 242, you have the option of operating
the IM 155-6 DP HF interface module as of 6ES7155-6BA00-0CN0 in DPV1 mode with more
than 244 bytes of parameter data. Configuration with the GSD file does not offer this option.
Reference
You can find additional information on identification data in the ET 200SP distributed I/O
system (http://support.automation.siemens.com/WW/view/en/58649293) system manual.
2.2
Functions
2.2.1
Functions
Introduction
The interface module supports the following functions:
● Identification data I&M 0 to 3
● PROFIBUS DP
● Firmware update via PROFIBUS DP
● Configuration control by means of the user program
● Operation as DPV1 slave
● Operation after Y-link (not with F-modules)
● Station extension via ET-Connection
● F-direct data exchange

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
