Interrupts, error messages, diagnostics and system alarms
5.2 Interrupts
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
35
The following table is used to explain the channel error entries:
Description
Channel number 0 to 63: Channel number for channel error
0x8000: Entire submodule
Channel properties Bit 0 to 7 00
H
: Free data type
01
H
: bit
02
H
: 2 bit
03
H
: 4 bit
04
H
: byte
05
H
: word
06
H
: Double word
07
H
bis FF
H
: Reserve
Bit 8 0: Channel
1: Channel group
Bit 9, 10 00
H
: Diagnostics
01
H
: Maintenance demanded
02
H
: Maintenance required
03
H
: Reserve
Bit 11, 12 00
H
: Channel error-free
01
H
: Incoming diagnostics
02
H
: Outgoing diagnostics
03
H
: Outgoing diagnostics, but other diagnostics are also
pending on this channel
Bit 13 to 15 00
H
: Reserve
01
H
: Input channel
02
H
: Output channel
03
H
: Input/output channel
Channel error type
Refer to respective manual for explanation.

Siemens SIMATIC ET 200SP IM 155-6 DP HF Specifications

General

Product type designation	IM 155-6 DP HF
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Interface	PROFIBUS DP
Protocol	PROFIBUS DP
Power Supply	24 V DC
Number of DP masters	1
DP master	Yes
Isochronous mode	Yes
Integrated web server	Yes
PROFINET IO Device	No
Number of IO controllers	0
IRT	No
MRP	No
MRPD	No
Shared device	No
Rated value (DC)	24 V
Permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Protection class	IP20
Mounting	DIN rail
Transmission rate	12 Mbps
Address area	244 bytes
I&M data	Yes
Number of S7 program blocks	0
Number of clock memories	0
Number of counters	0
Number of data blocks	0
Number of timers	0
Operating temperature	60 °C
Storage temperature	-40 °C to +70 °C
Relative humidity	95%
