Interrupts, error messages, diagnostics and system alarms
5.2 Interrupts
Interface module IM 155-6 DP HF (6ES7155-6BA01-0CN0)
Manual, 10/2018, A5E03916550-AD
37
The figure below shows an example of a diagnostic interrupt (part 2):
Figure 5-8 Example of a diagnostic interrupt (part 2)
Hardware interrupt of digital and analog input modules
The figure below shows the structure starting at byte x+4 for the hardware interrupt:
Figure 5-9 Structure starting at byte x+4 for hardware interrupt
