Installing and connecting the device
4.3 Connecting the device
SIMATIC Field PG M6
38 Operating Instructions, 12/2018, A5E43198909-AA
Connecting audio devices to the UAJ socket
The audio socket on the left-hand side of the device is a so-called UAJ connection (Universal
Audio Jack) for a 3.5mm jack.
Depending on the function, a UAJ connector has 2 to 4 contact areas. Depending on their
position, they are generally referred to as Tip, Ring 1, Ring 2 and Sleeve.
Depending on the function or standard, the contacts are assigned differently.
The audio controller of the Field PG recognizes the assignment of the contacts of the UAJ
connector depending on the connected audio device and is automatically configured.
You can connect the following audio devices to the UAJ connection:
● Audio device with line-out
● Audio device with line-in
● Headphones
● Microphone
● Headset (with headphones and microphone) with the following standards:
– OMTP: Standard for Samsung audio devices, etc.
– CTIA: Standard for Apple® audio devices
Note
Connection of microphone and headphones with two 3.5mm jacks
An adapter is needed to simultaneously connect a
microphone and headphones to a
3.5
-mm-jack.
See also
Technical specifications (Page 77)
