Technical specifications
9.3 Technical specifications
SIMATIC Field PG M6
Operating Instructions, 12/2018, A5E43198909-AA
77
9.3
Technical specifications
General technical data
Order nos. See order documents or rating plate
Dimensions
385 x 53 x 275 (W x H x D in mm)
Weight
• Without battery Approx. 3 kg
• With battery: Approx. 3.4 kg
Supply voltage (U
N
)
100 V to 240 V AC (±10%); sinusoidal
Line voltage frequency
50 - 60 Hz (47 to 63 Hz)
Power consumption AC
Max. 100 W
Output voltage of the power supply unit
(DC)
19 V
Output current of the power supply unit
(DC)
Max. 4.7 A
Output power of power supply unit (DC)
Max. 90 W
Standby power (in battery operation)
Typically 1.5 W
Lithium ion battery (9 cells) with detection
of charging condition)
Approx. 8250 mAh; 11.1 V with thermal switch and multi-
fuse; recyclable; chargeable up to 40° C; high number of
cycles for use in harsh environments; low self-discharge
Noise emissions
< 45 dB(A) according to ISO 7779
Degree of protection (entire device) IP 30 (with closed covers)
according to IEC 60529
Safety
Protection class
Safety class II according to IEC 61140
Safety specifications
• IEC 62368-1/EN 62368-1
• UL 62368-1 Second Edition
• CAN/CSA C22.2 No. 62368-1-14 Second Edition
