Operating the device
6.1 Notes on operation
SIMATIC Field PG M6
52 Operating Instructions, 12/2018, A5E43198909-AA
Editing SMCs, SD cards and multimedia cards
You can read, program or erase the following cards with the Multimedia Card Reader:
● SMC (SIMATIC MC)
● SD card (including SD UHS-II)
● MMC (Multi Media Card)
Risk of data loss for SIMATIC Micro Memory Card
Do not use a SIMATIC Micro Memory Card in this case because the card can be
damaged by Windows functions.
The slot for the SIMATIC Micro Memory Card is located on the right-hand side of the
device, see section "Modifying SIMATIC Micro Memory Cards (Page 53)".
The Multimedia Card Reader ① is located on the left-hand side of the device.
The contact areas of the card face downward. When inserting the card, pay attention to the
correct positioning of the card.
To remove the card press it lightly towards the device.
The card is operated by a push-push function.
Do not insert or remove cards while in use.
Inserting or removing a card while it is in use could damage it.
The card may not be removed as long the status indicator is lit, see section "Status displays
(Page 22)".
Observe the ESD guidelines (Page 75).
