Siemens SIMATIC Field PG M6 User Manual

Technical specifications
9.3 Technical specifications
SIMATIC Field PG M6
Operating Instructions, 12/2018, A5E43198909-AA
81
Interfaces
RS232/TTY interface (COM1)
• The RS232 interface is integrated in every device by
default.
• TTY interface (20 mA), depending on configuration,
cannot be retrofitted
Standard for "S5" equipment variants.
Active to 100 m, 25-pin socket, no galvanic isolation
or serial interface V.24
DVI-I Interface for external monitor (VGA screens can be oper-
ated using a DVI/VGA adapter), max. resolution
DVI/VGA: 1920 x 1200
DPP 1.2 (DisplayPort) Interface for external monitor, max. resolution:
4096 x 2560
USB
• 1x USB 3.1; Gen. 2; Type C (left-hand side of device):
Max. 1.5 A
• 1x USB 3.1; Gen. 2; Type A (back of device): Max.
0.9 A
• 1 x USB 3.0; Type A (right-hand side of device, top):
Max. 0.9 A
• 1 x USB 3.0; Type A (right-hand side of device, bot-
tom) with charging function for smartphone: Max.
1.5 A
PROFIBUS/MPI interface
9-pin sub-D socket
• Transmission speed • 9.6 kBaud to 12 Mbaud, software configured
• Mode of operation • Electrically isolated:
- Data channels A, B
- Control lines RTS AS, RTS_PG
- 5 V supply voltage (max. 90 mA)
Grounded:
- Shielding of the DP12 connection line
Physical port
RS485, electrically isolated
Ethernet
2 x Gigabit Ethernet (RJ45)
DC-In
DC power supply input, jack plug
Headphones, microphone, headset
UAJ connection for 3.5mm jack
