Siemens SIMATIC Field PG M6 User Manual

Technical specifications
9.4 Interface description
SIMATIC Field PG M6
84 Operating Instructions, 12/2018, A5E43198909-AA
USB 3.0/3.1; Type C
Pin no.
Short designation
Meaning
Input/output
A1
GND
Ground
–
A2
TX1+
Data cable (USB 3.0)
Output
A3
TX1-
Data cable (USB 3.0)
Output
A4
VBUS
+ 5 V (fused)
Output
A5
CC1
Configuration channel
Input/output
A6
D+
Data cable (USB 2.0)
Input/output
A7
D-
Data cable (USB 2.0)
Input/output
A8
-
Not assigned
-
A9
VBUS
+ 5 V (fused)
Output
A10
RX2-
Data cable (USB 3.0)
Input
A11 RX2+ Data cable (USB 3.0) Input
A12
GND
Ground
-
B1 GND Ground -
B2
TX2+
Data cable (USB 3.0)
Output
B3
TX2-
Data cable (USB 3.0)
Output
B4
VBUS
+ 5 V (fused)
Output
B5
VCONN
Configuration channel
Input/output
B6
D+
Data cable (USB 2.0)
Input/output
B7
D-
Data cable (USB 2.0)
Input/output
B8
-
Not assigned
-
B9
VBUS
+ 5 V (fused)
Output
B10
RX1-
Data cable (USB 3.0)
Input
B11
RX1+
Data cable (USB 3.0)
Input
B12
GND
Ground
-
