Installing and connecting the device
3.1 Preparing for installation
IFP Basic
22 Operating Instructions, 06/2023, A5E46178354 - AD
• Standard position: horizontal
• Inclined installation in horizontal format with a vertical inclination of maximum ±45 °
For horizontal installation, the following ambient temperatures are permitted:
Maximum ambient temperature at
Comment
45 °C (IFP1200 Basic, IFP1500 Basic,
IFP1900 Basic)
The device must be installed in a fire protection enclosure
(see "General safety instructions (Page 13)").
The device enclosure fulfills the requirement of a fire
protection enclosure.
• Vertical installation: display turned through ±90 ° compared with the standard position
