Installing and connecting the device
3.2 Mounting the device
SIMATIC IPC277G
Operating Instructions, 08/2021, A5E50059956-AA
27
The following table shows the type, number, and position of the mounting clips needed for
the respective devices.
IPC277G
device
Mounting clips
Type
Quantity
Position on the device
7" display
8
10" display
12
12" display 12
15" display 12
