Siemens SIMATIC IPC277G User Manual

Technical specifications
8.4 Technical data
SIMATIC IPC277G
90 Operating Instructions, 08/2021, A5E50059956-AA
Typical power consumption
Power consumption
(at 24 V rated voltage)
Size of the device
7"
10"
Device with Intel Atom® x6211E
18 W
21 W
Device with Intel Atom® x6413E
21 W
24 W
Device with Intel Atom® x6414RE
21 W
24 W
USB expansion
See section "Power demand of the components
(Page 89)"
M.2 Module
8.4.5 Power supply 12", 15", 19", 22" and 24" device
Technical specifications
Input voltage
24 VDC (19.2 to 28.8 VDC)
Power consumption
1
Max. 72 W
Maximum input current
5.0 A at 24 V
Buffering upon power failure
Hold-up time > 20 ms (after > 5 ms, DC_FAIL becomes
active)
Maximum continuous output power
1
80 W
1
: The power specifications apply to the power supply component, not to the device.
Note
Inrush current
The device needs an inrush current of at least 4.5 A for 25 ms.
The peak value of the inrush current depends on the input voltage and the impedance of the
24 V source; peak currents in excess of 4.5 A are possible. This will not have a negative
impact on device functionality.
Typical power consumption
Power consumption
(at 24 V rated voltage)
Size of the device
12"
15"
19"
22"
24"
Device with Intel
Atom® x6211E
32 W
33 W
39 W
33 W
43 W
Device with Intel
Atom® x6413E
35 W
36 W
42 W
36 W
46 W
Device with Intel
Atom® x6414RE
35 W
36 W
42 W
36 W
46 W
USB expansion
See section "Power demand of the components (Page 89)"
M.2 Module
