8.4 Technical data
SIMATIC IPC277G
Operating Instructions, 08/2021, A5E50059956-AA
83
8.4 Technical data
8.4.1 General technical specifications
General technical specifications
Size of the device
7" and 10" device
12", 15", 19", 22" and 24" device
Weight without mounting
brackets
• 7" device: Approx. 2460 g
• 10" device: Approx. 3210 g
• 12" device: Approx. 5100 g
• 15" device: Approx. 5290 g
• 19" device: Approx. 6680 g
• 22" device: Approx. 8120 g
• 24" device: Approx. 9550 g
Power supply
1
• 24VDC (19.2 to 28.8V)
• Rated output power: 30W
• 24VDC (19.2 to 28.8V)
• Rated output power: 80W
Power consumption (DC)
• 40%~60% full load, 24 VDC
at 85% efficiency
• Pout ≥ 6W, 24 VDC at 70%
efficiency
• Pout < 6W, 24 VDC at 50%
efficiency
• 50% to 100% nominal output power,
24VDC at 85% efficiency
Current consumption
• Max. 1.9 A at 24 V • Max. 5.0 A at 24 V
Noise emission
< 55 dB(A) according to DIN 45635-1
Degree of protection
• IP20 (Enclosure)
• IP65 (Front)
in accordance with IEC 60529
Protection class
Protection class III in accordance with IEC 61140
Pollution Degree
2
Quality assurance
In accordance with ISO 9001
1
: The device may only be connected to a 24 VDC power supply which meets the requirements of a
safe extra-low voltage (SELV/PELV) in accordance with IEC/EN/DIN EN/UL 61010-2-201.
