8.4 Technical data
SIMATIC IPC277G
84 Operating Instructions, 08/2021, A5E50059956-AA
Electromagnetic compatibility
Radiation Emission (Enclosure port)
in accordance with IEC 61000-6-3
+ A1/ CAN/CSA-CISPR 22:10
• 30 to 230MHz: 30dB(uV/m) quasi-peak(10m distance)
• 230 to 1000MHz: 37dB(uV/m) quasi-peak(10m distance)
• 1 to 3 GHz: 76dB(uV/m) peak; 56dB(uV/m) average (3m
distance)
• 3 to 6 GHz: 74dB(uV/m) peak; 54dB(uV/m) average (3m
distance)
Immunity with regard to
conducted interference on the
supply lines
• Burst: ± 2 kV (5 kHz /100 kHz) in accordance with IEC 61000-
4-4;
• Surge: ± 1kV line to line, ±2 kV line to earth in accordance
with IEC 61000-4-5;
Noise immunity on signal lines
Burst:
• ± 1 kV (5 kHz /100 kHz) in accordance with IEC 61000-4-4;
Length of signal port extension cable < 30 m;
• ± 2 kV (5 kHz /100 kHz) in accordance with IEC 61000-4-4;
Length of signal port extension cable ≥ 30 m;
Surge:
• ±2kV shielding-to-earth in accordance with IEC 61000-4-5;
Length of signal port extension cable ≥ 30 m;
Immunity to discharges of static
electricity
± 6 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference
Radiation Immunity (according to IEC 61000-6-2)
• 80 MHz to 2GHz
10 V/m, 80 % AM (1 kHz)
• 2 GHz to 6.0 GHz
3 V/m, 80 % AM (1 kHz)
Conducted Immunity (according to IEC 61000-4-6)
• 10 kHz to 80 MHz: 10 V, 80% AM (1kHz)
Conducted Emission (Low voltage
DC mains port), in accordance with
IEC 61000-6-3 + A1
• 0.15 to 0.5 MHz / 79 dB (μV) Q, 66 dB (μV) M
• 0.5 to 30 MHz / 73 dB (μV) Q, 60 dB (μV) M
Conducted
Emission(Telecommunications/Net
work Port),
in accordance with IEC 61000-6-3
+ A1
0.15 to 0.5 MHz:
84 dB(μV) to 74 dB(μV) Q
74 dB(μV) to 64 dB(μV) M
0.5 MHz to 30 MHz:
74 dB(μV) Q / 64 dB(μV) M
