Technical specifications
8.4 Technical data
SIMATIC IPC277G
Operating Instructions, 08/2021, A5E50059956-AA
85
Main circuit board
• Intel Atom® x6211E: Dual Core, 1.3 GHz, burst frequency 3.0
GHz, 6W TDP
• Intel Atom® x6413E: Quad Core, 1.5 GHz, burst frequency
3.0 GHz, 9W TDP
• Intel Atom® x6414RE: Quad Core, 1.5 GHz, 9W TDP
Memory expansion up to 16 GB with the following memory
modules:
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
The max speed of memory is up to 3200 MT/s.
The memory module supports IBECC function, and its default
value in BIOS is "Disable".
• Slot X100: support NGFF M.2
2230/2242/2260/2280/3030/3042/3052 with Key B/Key B+M
• Slot X101: support NGFF M.2
2230/2242/2260/3030/3042 with Key B/Key B+M
Max. permitted totally power loss
for each M.2 B key module
Less than 2.5 W
Drive, memory medium
• Slot X50: support NGFF M.2 2230/2242/2280 with Key
M/Key B+M
• 256GB Eco SSD
External, can be connected via USB port
