Technical specifications
8.4 Technical data
SIMATIC IPC277G
86 Operating Instructions, 08/2021, A5E50059956-AA
Graphics
Intel® Integrated UHD Graphic Controller
• 7" screen diagonal with backlighting,
resolution 800 × 480 pixels, WVGA (Wide Video Graphic
Array)
• 10" screen diagonal with backlighting,
resolution 1280 × 800 pixels, WVGA
• 12" screen diagonal with backlighting,
resolution 1280 × 800 pixels, WXGA (Wide XGA)
• 15" screen diagonal with backlighting,
resolution 1920 × 1080 pixels, Full HD (High Definition)
• 19" screen diagonal with backlighting,
resolution 1920 × 1080 pixels, Full HD
• 22" screen diagonal with backlighting,
resolution 1920 × 1080 pixels, Full HD
• 24" screen diagonal with backlighting,
resolution 1920 × 1080 pixels, Full HD
Projected capacitive touch screen <= 5 points
Half brightness life time, typical
• 7" min. 50000 h at 25 °C, 50% brightness
• 10" min. 50000 h at 25 °C,50% brightness
• 12" min. 70000 h at 25 °C, 50% brightness
• 15" min. 50000 h at 25 °C, 50% brightness
• 19" min. 50000 h at 25 °C, 50% brightness
• 22" min. 30000 h at 25 °C, 50% brightness
• 24" min. 30000 h at 25 °C, 50% brightness
Pixel error class in accordance with
ISO 9241-307
Resolution, graphics memory
• 2 × DP++, support resolution up to 4096 × 2160 pixel at 60Hz
Interfaces
3 × Gigabit Ethernet interface (three RJ45) electrically isolated,
Wake on LAN and Remote Boot are supported:
• X1P1: Marwell 88E1512
• X2P1: Marwell 88E1512
• X3P1: Marwell 88E1512
RS232/RS422/RS485
1
(optional), max. 115 Kbps, D-sub connector, 9-pin
