Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC277G
Operating Instructions, 08/2021, A5E50059956-AA
31
Procedure for mounting
Fasten the VESA adapter with the designated screws (M4).
Additional information
Dimension drawing of 12" device (Page 78)
Dimension drawing of 15" device (Page 79)
Dimension drawing of 19" device (Page 80)
Dimension drawing of 22" device (Page 81)
3.3 Connecting the device
3.3.1 Notes on connecting
Risk of fire and electric shock
The on/off switch does not isolate the device from the power supply. Risk of electric shock
exists if the device is opened incorrectly or defective. There is also a risk of fire if the device
or connecting lines are damaged. This can result in death and serious injury.
You should therefore protect the device as follows:
• Always pull out the power plug when you are not using the device or if the device is
defective. The power plug must be freely accessible.
• Use a central power isolating switch for cabinet installation.
