Expanding and assigning parameters to the device
6
6.1 Open the device
Requirement
• The device is disconnected from the power supply.
• All connecting cables on the device are removed.
• The device is removed from the cabinet.
• A T10 screwdriver
Procedure - Opening the 7" and 10" multi-touch devices
Remove the marked four screws on the rear panel of
the device.
Lift up the device's touch panel.
Unscrew the marked screws.
