Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC277G
36 Operating Instructions, 08/2021, A5E50059956-AA
Procedure
Switch off the 24 VDC power supply.
Connect the wires of the power supply.
Connect the connection terminal at the marked
position.
Secure the connection terminal with the marked
screws.
